. Homeowner: Keep Installation Instructions for future reference. Save Installation Instructions for local electrical inspector's use. Before you start Product dimensions Cabinet dimensions/requirements Electrical requirements Installation steps Check operation If range does not operate If you need assistance/service Moving the range Part No. 9757988 www.kitchenaid.com. Before you start. Your safety and the safety of others are very important.
Latest products at Home & Garden. Become a member and receive special benefits with purchases over €100. Food Dehydrator Instructions. Many are like me, and like to read instruction manuals. From Food Dehydrator Instructions to Dehydrators Home.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages.
This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. Product dimensions Freestanding Range 30' (76.2 cm) 8-1/4' cooktop (21 cm) width 1' (2.5 cm) spacer 27-3/4' (70.5 cm) depth with handle Cabinet dimensions/requirements Freestanding Range 13' (33 cm) max.
Upper cabinet depth 30' (76.2 cm) min. Cabinet opening width 18'. Slide-in ranges: countertop preparation The cooktop sides of the slide-in range fit over the cutout edge of your countertop.
If you have a square finish (flat) countertop and the opening width is 30' (76.2 cm), no countertop preparation is required. Formed front-edged countertops: Must have molded edge shaved flat 1/2'. WARNING Excessive Weight Hazard Use two or more people to move and install range. Failure to do so can result in back or other injury. Put on safety glasses and gloves. Remove shipping materials, tape and protective film from range. Keep cardboard bottom and shipping base under range.
Google Home Instruction Manual
Power supply cord method: NOTE: The bag containing three aluminum terminal lugs is not used when connecting the range using a power supply cord. WARNING Electrical Shock Hazard Disconnect power before servicing. Use a new 40 amp power supply cord. Plug into a grounded outlet. Direct wire method: Copper or Aluminum wire NOTE: The bag containing three aluminum terminal lugs must be used when making a direct wire connection.
WARNING Electrical Shock Hazard Disconnect power before servicing. Use 8 gauge copper or 6 gauge aluminum wire. Electrically ground range. Operating position Move range close to cabinet opening. Remove cardboard or hardboard from under range. Carefully move range into final position. Pull drawer open to first stop position.
Lift front of drawer to clear white wheels in drawer guides. Remove drawer and set it aside on a protected surface. Press the “CANCEL/OFF” pad. To get the most efficient use from your new electric range, read your KitchenAid Use and Care Guide. Keep Installation Instructions and Guide close to the electric range for easy reference.
If you need service: In the event that your KitchenAid appliance should need service, call the dealer from whom you purchased the appliance or a KitchenAid- authorized service company. ® HOME APPLIANCES Part No. 9757988 © 2003 KitchenAid ® Registered Trademark of KitchenAid. Prepared by KitchenAid, Benton Harbor, Michigan 49022 Printed in U.S.A.
